AMD Ryzen 7 8700G Processor

3 Years Warranty

Product Overview:

• Name: AMD Ryzen™ 7 8700G
• Family: Ryzen
• Series: Ryzen 8000 Series
• Market Segment: Desktop
• Architecture: Zen 4
• Former Codename: Phoenix
• Launch Date: Q1 2024

CPU Specifications:

• CPU Cores: 8
• Threads: 16
• Multithreading (SMT): Yes
• Max Boost Clock: Up to 5.1 GHz
• Base Clock: 4.2 GHz
• L2 Cache: 8 MB
• L3 Cache: 16 MB
• Default TDP: 65 W
• Configurable TDP: 45–65 W
• Processor Technology: TSMC 4nm FinFET
• Unlocked for Overclocking: Yes
• Precision Boost Technology: Precision Boost 2
• Precision Boost Overdrive: Yes
• AMD EXPO Memory Overclocking: Yes
• Ryzen Master Support: Yes
• CPU Socket: AM5

Memory Specifications:

• Memory Type: DDR5
• Memory Channels: 2
• Max Memory: 256 GB
• Max Memory Speed: DDR5-5200 (2 DIMM)
• ECC Support: Yes (Motherboard dependent)

Graphics Specifications:

• Graphics Model: AMD Radeon™ 780M
• Graphics Cores: 12
• Graphics Frequency: 2900 MHz
• DirectX Support: 12
• DisplayPort Version: 2.1
• HDMI Version: 2.1
• Multi Monitor Support: Yes
• Max Displays: 4
• AMD FreeSync: Yes
• Wireless Display: Miracast

Expansion Options:

• PCI Express Version: PCIe 4.0
• PCIe Lanes: 20 (16 usable)
• NVMe Support: Boot, RAID0, RAID1
• Native USB4: 2 Ports (40Gbps)
• USB 3.2 Gen2: 2 Ports
• USB 2.0: 1 Port

Package & Thermal Specifications:

• Socket: AM5
• Max Operating Temperature (TjMax): 95°C
• Package Die Count: 1
• CPU Die Size: 178 mm²

Supported Technologies:

• AMD Precision Boost 2
• Precision Boost Overdrive
• AMD EXPO Memory Technology
• AMD Ryzen Master Support
• AMD SmartAccess Memory
• AMD-V Virtualization
• AVX / AVX2 / AVX512 Support
• AES / FMA3 / SSE4.1 / SSE4.2
• x86-64 Instruction Set
