ASUS EX B365M V Motherboard (Used)

3 Months Warranty

Model:

• ASUS EX B365M V

Chipset:

• Intel® B365

CPU Support:

• Intel® Socket 1151 – 9th / 8th Gen Intel® Core™, Pentium® Gold & Celeron® Processors
• Supports Intel® 14nm CPU
• Supports Intel® Turbo Boost Technology 2.0
• Supports up to 65W CPUs

Memory:

• 2 x DIMM Slots
• Max 32GB DDR4
• DDR4 2666 / 2400 / 2133 MHz
• Non-ECC, Unbuffered
• Memory frequency varies by CPU

Graphics:

• Integrated Intel® HD Graphics Support
• 1 x HDMI Port
• HDMI 1.4b – Max Resolution 4096 × 2160 @30Hz

Expansion Slots:

• 1 x PCIe 3.0 x16 Slot (x16 mode)
• 2 x PCIe 3.0 x1 Slots

Storage:

• 4 x SATA 6Gb/s Ports

LAN:

• Realtek® RTL8111H Gigabit LAN

Audio:

• Realtek® ALC887 8-Channel HD Audio CODEC
• Front panel HD audio required for full 8-channel output

USB Ports:

• 6 x USB 3.1 Gen 1 (4 Rear + 2 Mid-board)
• 6 x USB 2.0 (2 Rear + 4 Mid-board)

Special Features:

• ASUS 5X Protection III
• SafeSlot Core
• Overvoltage Protection
• Stainless-Steel Back I/O
• DIGI+ VRM (5 Phase Digital Power Design)
• ESD Guards
• Anti-Moisture Coating
• USBGuard Protection
• Dedicated Audio PCB Layers
• ASUS Q-Slot
• ASUS Q-DIMM

Back Panel I/O:

• 4 x USB 3.1 Gen 1
• 2 x USB 2.0
• 1 x PS/2 Keyboard
• 1 x PS/2 Mouse
• 1 x HDMI
• 1 x LAN (RJ-45)
• 3 x Audio Jacks

Internal I/O:

• 1 x USB 3.1 Gen 1 Header (Supports 2 Ports)
• 2 x USB 2.0 Headers (Supports 4 Ports)
• 4 x SATA 6Gb/s
• 1 x CPU Fan Header
• 1 x Chassis Fan Header
• 1 x 24-pin ATX Power
• 1 x 8-pin ATX 12V Power
• 1 x Front Panel Audio (AAFP)
• 1 x Internal Speaker Header
• 1 x COM Debug Header
• 1 x Clear CMOS Jumper

BIOS:

• 128Mb Flash ROM
• UEFI AMI BIOS
• Multi-language BIOS

Manageability:

• WOL
• PXE

Operating System:

• Windows® 10 64-bit

Form Factor:

• Micro ATX
• 22.6 cm x 17.8 cm
