ASUS PRIME B450M K Motherboard (Used)

3 Months Warranty

Model:

• ASUS PRIME B450M K

CPU Support:

• AMD AM4 Socket
• Supports AMD Ryzen™ 5000 Series & 5000 G-Series
• Supports Ryzen™ 4000 G-Series
• Supports 3rd / 2nd / 1st Gen AMD Ryzen™ Processors
• Supports Ryzen™ with Radeon™ Vega Graphics
• Supports Athlon™ with Radeon™ Vega Graphics

Chipset:

• AMD B450 Chipset

Memory:

• 2 × DDR4 DIMM Slots
• Max Memory Capacity: 64GB
• DDR4 2133 / 2400 / 2666 MHz
• DDR4 2800 / 2933 / 3000 / 3200 / 3400 / 3466 / 3600 / 3733 / 3866 / 4000 / 4400 MHz (OC)
• Dual Channel Memory Architecture
• Supports ECC & Non-ECC Unbuffered Memory (ECC works in non-ECC mode)

Integrated Graphics (APU Required):

• DVI-D – Up to 1920 × 1200 @ 60Hz
• D-Sub – Up to 1920 × 1200 @ 60Hz
• Multi-VGA Output Support (DVI-D + D-Sub)

Expansion Slots:

• 1 × PCIe 3.0/2.0 x16 Slot (speed depends on CPU)
• 2 × PCIe 2.0 x1 Slots

Storage:

• 1 × M.2 Slot (PCIe 3.0 x4 & SATA)
• Supports 2242 / 2260 / 2280 M.2 SSDs
• 4 × SATA 6Gb/s Ports

RAID Support:

• Supports RAID 0 / RAID 1 / RAID 10
• NVMe PCIe RAID Supported

USB Ports:

• Rear: 2 × USB 3.1 Gen 2
• Rear: 4 × USB 3.1 Gen 1
• Internal: USB 3.1 Gen 1 Header (2 Ports)
• Internal: USB 2.0 Headers (4 Ports)

LAN:

• Realtek® RTL8111H Gigabit LAN
• ASUS LAN Guard Protection

Audio:

• Realtek® ALC887 8-Channel HD Audio
• LED-Illuminated Audio Path
• Audio Shielding & Dedicated PCB Layers
• Premium Japanese Audio Capacitors

Back I/O Ports:

• 2 × USB 3.1 Gen 2
• 4 × USB 3.1 Gen 1
• 1 × DVI-D
• 1 × D-Sub
• 1 × LAN (RJ-45)
• 3 × Audio Jacks
• PS/2 Keyboard & Mouse Ports

Internal Connectors:

• 24-pin ATX Power + 8-pin CPU Power
• 1 × CPU Fan Header
• 1 × Chassis Fan Header
• COM Port Header
• S/PDIF Out Header

Operating System Support:

• Windows® 10 64-bit
• Windows® 7 64-bit (Ryzen 1st / 2nd Gen only)

Form Factor:

• Micro-ATX (22.6 × 22.1 cm)
