ASUS PRIME Z590 P Motherboard

3 Months Warranty

Model:

• ASUS PRIME Z590 P

CPU Support:

• Intel® LGA1200 Socket
• Supports 11th Gen Intel® Core™ Processors
• Supports 10th Gen Intel® Core™, Pentium® Gold & Celeron®
• Intel® Turbo Boost 2.0 / Turbo Boost Max 3.0 (CPU dependent)

Chipset:

• Intel® Z590 Chipset

Memory:

• 4 × DDR4 DIMM Slots
• Max Memory: 128GB
• DDR4 5133(OC) / 5000(OC) / 4800(OC) / 4700(OC) / 4600(OC) / 4500(OC) / 4400(OC) / 4266(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3400(OC) / 3333(OC) / 3200 / 3000 / 2933 / 2800 / 2666 / 2400 / 2133 MHz
• Dual Channel Architecture
• Intel® XMP Support
• ASUS OptiMem II

Onboard Graphics (CPU Dependent):

• 1 × DisplayPort 1.4
• 1 × HDMI™ (11th Gen CPU: HDMI 2.0 up to 4K@60Hz | 10th Gen CPU: HDMI 1.4 up to 4K@30Hz)

Expansion Slots:

• 1 × PCIe 4.0/3.0 x16 Slot (CPU)
• 1 × PCIe 3.0 x16 Slot (x4 mode, Chipset)
• 2 × PCIe 3.0 x1 Slots

Storage:

• 3 × M.2 Slots (Key M)
• M.2_1 (CPU): 2242/2260/2280/22110 (PCIe 4.0 x4 - 11th Gen CPU only; disabled with other CPUs)
• M.2_2 (Chipset): 2242/2260/2280 (PCIe 3.0 x4 & SATA)
• M.2_3 (Chipset): 2242/2260/2280/22110 (PCIe 3.0 x4 & SATA)
• 4 × SATA 6Gb/s Ports
• Intel® Rapid Storage Technology (RST) Support
• Intel® Optane™ Memory Support (PCH-attached slots)
• Note: If an M.2 SATA device is installed in M.2_2, SATA6G_2 port is disabled

LAN & Wireless:

• Realtek® 2.5Gb Ethernet
• V-M.2 (Key E) Slot for optional Wi-Fi module (module/bracket sold separately)

USB (Rear I/O):

• 1 × USB 3.2 Gen 2x2 Type-C®
• 1 × USB 3.2 Gen 2 Type-A
• 2 × USB 3.2 Gen 1 Type-A
• 2 × USB 2.0 Type-A

USB (Front / Internal):

• 1 × USB 3.2 Gen 1 Type-C® front connector
• 2 × USB 3.2 Gen 1 headers (adds up to 4 ports)
• 2 × USB 2.0 headers (adds up to 4 ports)
• Note: USB_E1/USB_E2/USB_E3/USB_E4 share bandwidth

Audio:

• Realtek® ALC897 7.1 HD Audio
• Rear Optical S/PDIF Out
• Audio Shielding + Dedicated PCB Layers
• Premium Japanese Audio Capacitors

Back Panel I/O:

• 1 × USB 3.2 Gen 2x2 Type-C®
• 1 × USB 3.2 Gen 2 Type-A
• 2 × USB 3.2 Gen 1 Type-A
• 2 × USB 2.0 Type-A
• 1 × DisplayPort
• 1 × HDMI™
• 1 × V-M.2 (Key E) Slot
• 1 × Realtek 2.5Gb LAN
• 5 × Audio Jacks
• 1 × Optical S/PDIF Out
• 1 × PS/2 Keyboard/Mouse Combo

Internal Connectors:

• Power: 24-pin ATX + 8-pin CPU + 4-pin CPU
• Fan Headers: 1 × CPU Fan, 1 × AIO Pump, 3 × Chassis Fans
• 2 × AURA Addressable Gen 2 Headers
• 2 × AURA RGB Headers
• SPI TPM Header
• COM Port Header
• Thunderbolt™ Header
• Clear CMOS Header

Special Features:

• ASUS 5X Protection III
• DIGI+ VRM (Digital power design with DrMOS)
• LANGuard + Overvoltage Protection
• SafeSlot Core+ + Stainless-Steel Back I/O
• Flexible M.2 Heatsink + VRM Heatsink Design
• AURA Sync (RGB + Addressable Gen 2)

BIOS:

• UEFI AMI BIOS (192Mb)
• ASUS EZ Flash 3
• ASUS CrashFree BIOS 3

Manageability:

• WOL by PME
• PXE
