COLORFUL CH510M K M.2 EVO V20 Motherboard

3 Years Warranty

Model:

• COLORFUL CH510M K M.2 V20
• Product Series: COLORFUL Series

CPU:

• LGA1200 Socket
• Supports 11th & 10th Gen Intel® Core™, Pentium® & Celeron® Processors

Chipset:

• Intel® H510 / H470 Chipset

Memory:

• 2 × DDR4 DIMM Slots
• Max Memory: 64GB (32GB per DIMM)
• Dual Channel Architecture
• DDR4-2933 / 2800 / 2666 / 2400 / 2133 MHz
• Up to 3200MHz with 11th Gen Intel® Processors
• Supports Intel® XMP (Extreme Memory Profile)

Expansion Slots:

• 1 × PCIe 3.0 x16 Slot
• 1 × PCIe 3.0 x1 Slot

Storage:

• 1 × M.2 Slot (2242 / 2280, PCIe 3.0 x4 via PCH)
• 4 × SATA 6Gb/s Ports
• Supports RAID 0 / 1 / 5 / 10 (SATA)

Rear I/O Ports:

• 1 × PS/2 Port
• 2 × USB 2.0
• 4 × USB 3.2 Gen 1 Type-A
• 1 × HDMI 1.4 (Up to 4K @30Hz)
• 1 × VGA (D-Sub)
• 1 × Gigabit LAN Port
• 3 × Audio Jacks (Line In / Line Out / Mic)

Internal Connectors:

• 2 × CPU Fan Headers
• 1 × System Fan Header
• 1 × USB 2.0 Header (Expands 2 Ports)
• 1 × USB 3.2 Gen 1 Header (Expands 2 Ports)
• 1 × Front Panel Audio Header
• 1 × Front Panel Header
• 1 × Speaker Header
• 1 × COM Port Header
• 1 × Clear CMOS Jumper
• 1 × ME Write Protection Jumper
• 1 × BIOS Flash/Burner Pin
• 1 × Wake-up Control Jumper

LAN:

• Realtek® RTL8111H Gigabit LAN

Audio:

• 7.1 Channel Audio Support

BIOS:

• 128M UEFI BIOS
• Multi-language Support

Hardware Monitoring:

• CPU & System Fan Speed Control
• CPU & System Temperature Monitoring
• Voltage Monitoring

Power Management:

• Supports S3 / S4 / S5 Wake-up
• Network Wake (S5)
• USB Wake-up
• Scheduled Boot & Auto Power On

Form Factor:

• Micro-ATX
• 236mm × 188mm
