Gigabyte A520M K V2 Motherboard

3 Years Warranty

Product Overview:

• Product Name: Gigabyte A520M K V2 Motherboard
• Socket: AMD AM4
• Chipset: AMD A520
• Form Factor: Micro-ATX
• Condition: Brand New

CPU Support:

• Supports AMD Ryzen™ 5000 G-Series Processors
• Supports AMD Ryzen™ 5000 Series Processors
• Supports AMD Ryzen™ 4000 G-Series Processors
• Supports AMD Ryzen™ 3000 & Ryzen™ 3000 G-Series Processors

Memory Specifications:

• Memory Type: DDR4
• DIMM Slots: 2
• Max Memory Capacity: 64GB
• Supports DDR4 5100(OC) / 4800(OC) / 4600(OC) / 4400(OC) / 4266(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3400(OC) / 3200 / 2933 / 2667 / 2400 / 2133 MHz
• Supports Dual Channel Memory
• Supports ECC & Non-ECC Unbuffered Memory
• Supports AMD XMP Memory Profiles

Graphics Outputs:

• HDMI: 1 × HDMI 2.1 with HDR (Up to 4096 × 2160 @60Hz)
• VGA: 1 × D-Sub (Up to 1920 × 1200 @60Hz)
• Maximum Shared Graphics Memory: 16GB
• Available only with CPUs featuring integrated graphics

Expansion Specifications:

• PCI-E x16 Slots: 1
• PCI-E x1 Slots: 1
• PCIe x16: PCIe 3.0 x16 (From CPU)
• PCIe x1: PCIe 3.0 x1 (From Chipset)

Storage Specifications:

• M.2 Slots: 1
• M.2_1: PCIe 3.0 x4/x2 & SATA (2280)
• SATA III Ports: 4
• RAID Support: RAID 0 / 1 / 10

USB Connectivity:

• USB 3.2 Gen 1 (Rear): 4
• USB 3.2 Gen 1 (Front): 2
• USB 2.0 (Rear): 2
• USB 2.0 (Front): 4

Audio & Networking:

• Audio Codec: Realtek® High Definition Audio Codec
• Audio Channels: 2 / 4 / 5.1 / 7.1 Channel HD Audio
• LAN: Realtek® Gigabit Ethernet (10/100/1000 Mbps)

Internal Features:

• 1 × 24-Pin ATX Power Connector
• 1 × 8-Pin CPU Power Connector
• 1 × CPU Fan Header
• 1 × System Fan Header
• 1 × M.2 Socket
• 4 × SATA III Ports
• 1 × Front Panel Header
• 1 × Front Audio Header
• 1 × USB 3.2 Gen 1 Header
• 2 × USB 2.0 Headers
• 1 × TPM Header
• 1 × Speaker Header
• 1 × Clear CMOS Jumper
• 1 × Chassis Intrusion Header

Rear I/O Ports:

• 1 × PS/2 Keyboard/Mouse
• 1 × HDMI
• 1 × VGA
• 4 × USB 3.2 Gen 1
• 2 × USB 2.0
• 1 × RJ-45 Gigabit LAN
• 3 × Audio Jacks

Supported Technologies:

• PCIe 3.0 Support
• AMD XMP Memory Overclocking
• TPM Support
• Q-Flash BIOS Update
• Smart Backup
• EasyTune
• APP Center
• Windows 11 / Windows 10 64-bit Support
