GIGABYTE B650M D2HP MOTHERBOARD

3 Years Warranty

Model:

• • • GIGABYTE B650M D2HP

CPU Support:

• • • AM5 Socket
    • Supports Ryzen™ 7000 / 8000 / 9000 Series Processors

Chipset:

• • • AMD B650 Chipset

Memory:

• • • 2 × DDR5 DIMM Slots
    • Max Memory: 128GB (64GB per DIMM)
    • Dual Channel Architecture
    • DDR5 6400(OC) / 6200(OC) / 6000(OC) / 5600(OC) / 5200 / 4800 / 4400 MT/s
    • Supports AMD EXPO™ & XMP
    • Non-ECC Unbuffered DIMM Support

Onboard Graphics (CPU Dependent):

• • • D-Sub (1920×1200 @60Hz)
    • HDMI 2.1 (4096×2160 @60Hz)

Audio:

• • • Realtek® High Definition Audio
    • 2 / 4 / 5.1 / 7.1 Channel Support

LAN & Wireless:

• • • Realtek® 2.5GbE LAN
    • Wi-Fi 802.11 a/b/g/n/ac (2.4GHz / 5GHz Dual Band)
    • Bluetooth 4.2

Expansion Slots:

• • • 1 × PCIe 4.0 x16 Slot (CPU Integrated)
    • 1 × PCIe 3.0 x1 Slot (Chipset)

Storage:

• • • 1 × M.2 PCIe 4.0 x4 Slot
    • 4 × SATA 6Gb/s Ports
    • RAID 0 / 1 / 10 Support (NVMe & SATA)

USB:

• • • 2 × USB 3.2 Gen 1 (Rear)
    • 2 × USB 3.2 Gen 1 (Front Header)
    • USB 2.0 Rear + Front Header Support

Internal Connectors:

• • • 24-pin ATX Power + 8-pin CPU Power
    • CPU Fan + 2 × System Fan Headers
    • 2 × Addressable RGB + 1 × RGB Header
    • TPM Header
    • USB 3.2 Gen 1 & USB 2.0 Headers

Back Panel I/O:

• • • PS/2 Combo Port
    • D-Sub + HDMI
    • 2 × USB 3.2 Gen 1
    • 4 × USB 2.0
    • RJ-45 2.5G LAN
    • 3 × Audio Jacks
    • Q-Flash Plus Button

BIOS:

• • • 256 Mbit AMI UEFI BIOS
    • Q-Flash & Q-Flash Plus Support

Operating System:

• • • Windows 11 64-bit
    • Windows 10 64-bit

Form Factor:

• • • Micro-ATX (24.0cm × 22.5cm)
