MAXSUN TERMINATOR B650M WIFI6 MOTHERBOARD

3 YEARS Warranty

Model:

• MS TERMINATOR B650M WIFI6

Chipset:

• AMD® B650 chipset

CPU Support:

• AMD AM5 socket
• Supports AMD Ryzen™ 7000, 8000, and 9000 series processors
• Maximum CPU TDP support: 170W

Memory:

• 4 × DDR5 DIMM slots
• Dual-channel memory architecture
• Supported memory speeds:
  4800 / 5200 / 5600(OC) / 6000(OC) / 6400(OC) / 6800(OC) / 7000(OC) / 7200(OC) / 7600(OC) / 7800(OC) / 8000(OC) MHz

Display Outputs:

• 1 × HDMI™ port, up to 4096×2160 @ 30Hz (HDCP 2.2 support)
• 1 × DisplayPort, up to 4096×2160 @ 60Hz

Expansion Slots:

• 1 × PCIe 5.0 x16 slot
• 1 × PCIe 4.0 x4 slot
• 1 × PCIe 3.0 x1 slot

Storage:

• 1 × M.2 slot (supports 2242 / 2280 / 22110 PCIe 4.0 x4/x2 SSDs)
• 4 × SATA 6Gb/s ports

USB Ports:

• Rear I/O: 4 × USB 3.2 Gen1 ports, 4 × USB 2.0 ports, 1 × USB Type-C (10Gbps)
• Internal headers: 1 × USB 2.0 header (2 ports), 1 × USB 3.2 Gen1 header (2 ports), 1 × front USB Type-C (10Gbps)

LAN:

• Realtek® RTL8125BG 2.5Gb Ethernet controller

Audio:

• Realtek® ALC897 audio codec

Internal I/O & Headers:

• 1 × 24-pin ATX power connector
• 1 × 8-pin ATX 12V CPU power connector
• 1 × CPU fan header
• 2 × system fan headers
• 1 × PS/2 interface
• 1 × 4-pin speaker header
• 1 × front panel audio header
• 1 × COM_A header
• 1 × 9-pin DEBUG_CON header
• 1 × CLR CMOS jumper

Operating System Support:

• Windows® 11 64-bit
• Windows® 10 64-bit

Form Factor:

• Micro-ATX (245 × 245 mm)
