MSI MAG A850GLS PCIE5 80 PLUS Gold Power Supply Unit

3 Years Warranty

Product Overview:

• Product Name: MSI MAG A850GLS PCIE5
• Product Type: ATX Power Supply Unit
• Output Power: 850W
• Efficiency Rating: 80 PLUS Gold (Up to 90%)
• Modular Design: Fully Modular
• Condition: Brand New

Power Specifications:

• Total Output Power: 850W
• Peak Power Excursion: 1870W (Up to 220% for 100μs)
• Input Voltage Range: 100–240V AC
• Input Frequency Range: 47–63Hz
• PFC Type: Active PFC

Cooling & Design:

• Fan Size: 135mm
• Fan Bearing: Fluid Dynamic Bearing
• Cooling Type: Active Air Cooling

Protection Features:

• OCP (Over Current Protection)
• OTP (Over Temperature Protection)
• OPP (Over Power Protection)
• SCP (Short Circuit Protection)
• OVP (Over Voltage Protection)
• UVP (Under Voltage Protection)
• SIP (Surge & Inrush Protection)
• NLO (No Load Operation)

Cable & Connectors:

• ATX (24-Pin): 1
• EPS (8-Pin): 1
• EPS (4+4 Pin): 1
• PCI-E 5.1 (16-Pin): 1 (600W)
• PCI-E (6+2 Pin): 4
• SATA (15-Pin): 8
• Peripheral (4-Pin): 3
• FDD (4-Pin): 1

Dimensions:

• Product Size: 150 × 150 × 86 mm

Supported Technologies:

• 80 PLUS Gold Efficiency
• ATX 3.1 Ready
• PCIe 5.1 Ready (600W 16-Pin)
• Fully Modular Cable Design
• Active PFC Power Correction
• Fluid Dynamic Bearing Fan
• Multi-Protection Safety Design
