AMD Ryzen 5 3400G Processor

3 Years Warranty

Product Overview:

• Name: AMD Ryzen™ 5 3400G with Radeon™ RX Vega 11 Graphics
• Family: Ryzen
• Series: Ryzen 3000 Series
• Form Factor: Desktop (Boxed Processor)
• Market Segment: Mainstream Desktop
• Former Codename: Picasso
• Processor Architecture: Zen+

CPU Specifications:

• Total Cores: 4
• Total Threads: 8
• Base Clock: 3.7 GHz
• Max Boost Clock: Up to 4.2 GHz
• L1 Cache: 384 KB
• L2 Cache: 2 MB
• L3 Cache: 4 MB
• Default TDP: 65 W
• Configurable TDP (cTDP): 45–65 W

Manufacturing & Design:

• CPU Core Process: 12 nm FinFET
• CPU Die Size: 210 mm²
• Total Transistor Count: 4.94 Billion
• Unlocked for Overclocking: Yes

Platform & Expansion:

• CPU Socket: AM4
• Supported Chipsets: X570, X470, X370, B450, B350, A320
• PCI Express Version: PCIe® 3.0
• Native PCIe Lanes: 20 (16 usable)
• NVMe Support: Boot, RAID0, RAID1, RAID10

Memory Specifications:

• System Memory Type: DDR4
• Memory Channels: 2
• Maximum Memory: 64 GB
• Max Memory Speed: DDR4-2933 (dual-rank dependent)
• ECC Support: Yes (requires motherboard support)

Graphics:

• Graphics Model: Radeon™ RX Vega 11
• Graphics Core Count: 11
• Total Graphics Shaders: 704
• Graphics Frequency: 1400 MHz
• Max GPU Memory: 2 GB
• Max Displays Supported: 3
• DirectX® Support: 12
• OpenGL® Support: 4.6
• AMD FreeSync™ Support: Yes

Cooling & OS Support:

• Included Cooler: AMD Wraith Spire
• Max Operating Temperature (Tjmax): 95°C
• Windows 10 (64-bit)
• RHEL x86 64-bit
• Ubuntu x86 64-bit

Additional Information:

• Launch Date: 07 July 2019
• AMD PRO Technologies: No
