ASUS EX H610M V3 Motherboard (Used)

3 Months Warranty

Model:

• ASUS EX H610M V3

Socket:

• LGA1700
• Supports 14th, 13th & 12th Gen Intel® Core™, Pentium® Gold & Celeron®
• Supports Intel® Turbo Boost 2.0 & Turbo Boost Max 3.0*

Chipset:

• Intel® H610 Chipset

Memory:

• 2 x DDR4 DIMM Slots
• Max 64GB (Dual Channel)
• Supports DDR4 3200 / 3000 / 2933 / 2800 / 2666 / 2400 / 2133 MHz
• Supports XMP
• Non-ECC, Un-buffered Memory

Graphics Output:

• 1 x HDMI® (Supports 4K@60Hz – HDMI 2.1)
• *Requires CPU with integrated graphics

Expansion Slots:

• 1 x PCIe 4.0 x16
• 1 x PCIe 3.0 x1

Storage:

• 3 x SATA 6Gb/s Ports

Ethernet:

• Realtek 1Gb Ethernet

USB Ports:

• Rear: 2 x USB 3.2 Gen 1 + 4 x USB 2.0
• Front: 2 x USB 3.2 Gen 1 + 2 x USB 2.0 (via headers)

Audio:

• Realtek 7.1 HD Audio Codec
• Supports 24-bit / 192kHz Playback
• Audio Shielding & Dedicated PCB Layers

Back Panel I/O:

• 2 x USB 3.2 Gen 1
• 4 x USB 2.0
• 1 x HDMI
• 1 x 1Gb LAN
• 3 x Audio Jacks
• 1 x PS/2 Combo Port

Internal I/O:

• 1 x 24-pin ATX Power
• 1 x 8-pin 12V Power
• 1 x CPU Fan Header
• 1 x Chassis Fan Header
• 3 x SATA Ports
• 1 x USB 3.2 Gen 1 Header
• 1 x USB 2.0 Header
• 1 x Front Panel Audio (AAFP)
• 1 x Clear CMOS Header
• 1 x Speaker Header
• 1 x System Panel Header

Special Features:

• ASUS 5X Protection III
• DIGI+ VRM
• SafeSlot Core
• Lightning Boot
• Anti-moisture Coating
• USBGuard
• Aluminum Heatsink Design

BIOS:

• 128 Mb UEFI AMI BIOS

Operating System:

• Windows® 11 64-bit
• Windows® 10 64-bit

Form Factor:

• Micro ATX
• 23.4 cm x 20.3 cm
