ASUS PRIME A320M K MOTHERBOARD (USED)

3 Months Warranty

Model:

• ASUS PRIME A320M-K

CPU Support:

• AMD AM4 Socket
• Supports 3rd / 2nd / 1st Gen AMD Ryzen™ Processors
• Supports Ryzen™ with Radeon™ Vega Graphics
• Supports Athlon™ with Radeon™ Vega Graphics
• Supports 7th Gen A-Series & Athlon™ X4 Processors

Chipset:

• AMD A320 Chipset

Memory:

• 2 × DDR4 DIMM Slots
• Max Memory: 64GB (Ryzen CPUs)
• Max Memory: 32GB (A-Series / Athlon X4)
• DDR4 2133 / 2400 / 2666 MHz
• DDR4 2800 / 2933 / 3000 / 3200 MHz (OC)
• Dual Channel Memory Architecture
• Supports ECC & Non-ECC UDIMM (ECC works in non-ECC mode)

Integrated Graphics (APU Required):

• HDMI 1.4b – Up to 4096×2160 @24Hz
• D-Sub – Up to 1920×1200 @60Hz
• Multi-VGA Output Support (HDMI + D-Sub)
• Maximum Shared Memory: 2048MB

Expansion Slots:

• 1 × PCIe 3.0/2.0 x16 Slot (speed depends on CPU)
• 2 × PCIe 2.0 x1 Slots

Storage:

• 1 × M.2 Slot (PCIe 3.0 x4 & SATA)
• Supports 2242 / 2260 / 2280 M.2 SSDs
• 4 × SATA 6Gb/s Ports

RAID Support:

• Supports RAID 0 / RAID 1 / RAID 10

USB Ports:

• Rear: 4 × USB 3.2 Gen 1 (Blue)
• Rear: 2 × USB 2.0
• Internal: USB 3.2 Gen 1 Header (2 Ports)
• Internal: USB 2.0 Headers (4 Ports)

LAN:

• Realtek® RTL8111H Gigabit LAN

Audio:

• Realtek® ALC887 / ALC897 HD Audio Codec
• 8-Channel High Definition Audio

Back I/O Ports:

• 4 × USB 3.2 Gen 1
• 2 × USB 2.0
• 1 × HDMI
• 1 × D-Sub
• 1 × LAN (RJ-45)
• 3 × Audio Jacks
• PS/2 Keyboard & Mouse Ports

Internal Connectors:

• 1 × CPU Fan Header
• 1 × Chassis Fan Header
• 24-pin ATX + 4-pin CPU Power
• COM Port Header
• TPM Header

Operating System Support:

• Windows® 10 64-bit
• Windows® 7 64-bit (Limited CPU Support)

Form Factor:

• Micro-ATX (22.6 × 22.1 cm)
